Description
|
LSI MegaRAID SAS 9266-4i SGL Single Pack, PCI-e 2.0 x8, 6Gb/s throughput per port, LSISAS2208 Dual Core ROC, 4-port Internal SAS/SATA RAID 0, 1, 5, 6, 10, 50 ,60, 1 x internal mini-SAS connectors(SFF-8087), 1GB DDRIII cache, Low Profile, support up to 128 SAS/SATA hard drives or SSDs, optional BBU(direct attach LSIiBBU09) and CacheVault Module(LSICVM01).
The four-port MegaRAID SAS 9266-4i, built on dual-core 6Gb/s MegaRAID SAS technology, combines the industry�s highest RAID performance with intelligent flash-based caching and enhanced data protection capabilities
The eight-port MegaRAID SAS 9266-8i, built on dual-core 6Gb/s MegaRAID SAS technology, combines the industry�s highest RAID performance with intelligent flash-based caching andenhanced data protection capabilities
Features
- Four internal SATA+SAS ports - One mini-SAS SFF-8087 x4 connector side mount - 6Gb/s throughput per port - LSISAS2208 Dual Core ROC - 800MHz PowerPC� - MD2 Low profile (6.6 inch X 2.536 inch) - x8 PCI Express� 2.0 host interface - 1GB DDRIII cache (1333MHz) - Optional CacheVault Module (LSICVM01) - Optional battery backup unit (LSIiBBU09) - Connect up to 128 SATA and/or SAS devices - RAID levels 0, 1, 5 and 6 - RAID spans 10, 50 and 60
|
Detailed Description
|
New Page 1

Features
- Four internal SATA+SAS ports
- One mini-SAS SFF-8087 x4
connector – side mount
- 6Gb/s throughput per port
- LSISAS2208 Dual Core ROC
o 800MHz PowerPC®
- MD2 Low profile (6.6" X
2.536")
- x8 PCI Express® 2.0 host
interface
- 1GB DDRIII cache (1333MHz)
- Optional CacheVault Module
(LSICVM01)
- Optional battery backup unit
(LSIiBBU09)
- Connect up to 128 SATA and/or
SAS devices
- RAID levels 0, 1, 5 and 6
- RAID spans 10, 50 and 60
Benefits
- Second generation 6Gb/s SATA+SAS
with unprecedented levels of performance
- Ideal for internal storage
environments using up to 128 SAS, SATA and solid state drives
(SSDs)
- Unsurpassed IOPs performance and
advanced software options help users realize full benefits of
SSD deployments
- CacheVault technology option for
greener, lower total cost cache protection
- Support for MegaRAID CacheCade®
Pro 2.0 read/write caching software to accelerate I/O
performance of existing HDD arrays using SSDs as
high-performance cache.
- Meets high I/O transaction
demands of database and datacenter applications
- Provides the sustained data
transfer rates and high sequential bandwidth to meet
processing requirements of digital media, video and imaging
environments
|
Specifications :
|
Warranty Details
|
Warranty Period :
3
Years
|
|
|
