Part Number: LSI00289
Category
Storage Devices
 Controllers
  LSI LOGIC
   BATTERY BACKUP OPTIONS
Buy Price GST Ex Buy Price GST Inc
$174.55 $192.00
Stock GST Rate
Call 10%
Description
LSI MegaRAID FastPath Electronic Software License provides high-performance I/O acceleration for SSDs CONNECTED TO A 6Gb/s MegaRAID SATA+SAS controller, to dramatically boost transactional application throughput

- Provides high-performance I/O acceleration for SSDs connected to a 6Gb/s MegaRAID SATA+SAS controller
- Supports full optimization of SSD volumes to deliver up to 3X improvement in
read and write I/Os per second (IOPS) compared to controllers without FastPath
enabled
Detailed Description
New Page 1



Features

  • Provides high-performance I/O acceleration for SSDs connected to a 6Gb/s MegaRAID SATA+SAS controller
  • Boosts performance of 2208-based MegaRAID controllers to more than 465,000 IOPS and 2108-based MegaRAID controllers to more than 150,000 IOPS
  • Accelerates performance up to 3X that of MegaRAID controllers not using FastPath software

Benefits

  • Supports full optimization of SSD virtual disk groups to deliver up to a 3X improvement in read and write IOPs compared to MegaRAID controllers not utilizing MegaRAID FastPath software
  • Performance levels reached with this solution are equivalent to those of much costlier Flash-based adapter card solutions
  • Improves the performance of existing web servers or can provide the same performance with fewer web servers, lowering the total cost of ownership

Specifications :

LSI™ MegaRAID® Fast Path Software

Software License Ordering PN LSI00266 - Compatible with all 6Gb/s MegaRAID SATA+SAS products
(with the exception of 9240 series)
Physical Key Ordering PN

LSI00247 - Compatible products include 9260-4i, 9260-8i, 9280-4i4e, 9260-16i, 9280-16i4e, 9280-24i4e
LSI00289 - Compatible with 9265-8i, 9285-8e
Supported Operating Systems

All supported operating systems
Supported SSDs


No restrictions.

Please visit www.lsi.com/channel/support/marketing_resources for a complete list of tested SSDs.







Warranty Details
Warranty Period : 5 Years
