Part Number: LSI00290
Category
Storage Devices
 Controllers
  LSI LOGIC
   BATTERY BACKUP OPTIONS
Buy Price GST Ex Buy Price GST Inc
$424.55 $467.00
Stock GST Rate
Call 10%
Description
LSI MegaRAID CacheCade Pro 2.0 Software

- Dynamic Read and Write caching of hot spot data for significant reduction in I/O
latency
- Accelerates I/O performance of existing HDD arrays using SSDs as high - performance cache
- Optimized for real-world workloads of transaction-intensive applications

Detailed Description
New Page 1



Features

  • Read and Write caching software for 6Gb/s MegaRAID® SATA+SAS controller cards
  • Leverages SSDs in front of HDD volumes to create high-capacity, high-performance controller cache pools
  • Automatic, dynamic "Hot" classification of data being written and being read
  • RAID 1, 10 SSD Write Cache protection
  • Configuration through MegaRAID Storage Manager™ with standard virtual drives

Benefits

  • Accelerates performance of existing HDD arrays with small upfront investment
  • Read and Write caching of hot spot data for significant reduction in I/O latency
  • Simple, intuitive management tools to assign and manage CacheCade™ SSD pool
  • Faster I/O performance from SSD cache reduces need to short-stroke large number of HDDs, yielding lower TCO

Specifications :


LSI MegaRAID® CacheCade™ Software

Software License Ordering PN LSI00293 - Compatible with MR SAS 9260/9261/9265/9266/9280/9285 series
Physical Key Ordering PN
LSI00292 - Compatible with MR SAS 9260 (-4i, -8i, -16i, CV-4i, CV-8i), 9280 (-4i4e, -16i4e, -24i4e)
LSI00290 - Compatible with MR SAS 9265-8i, 9266 (-4i, -8i), 9285 (-8e, CV-8e)
Supported Operating Systems
All operating systems supported by MegaRAID controller card
Supported SSDs
Please visit www.lsi.com/channel for a complete list of tested SSDs
Max. Number of SSD in a CacheCade SSD Pool
32
Max. Number of SSC VD Supported per Controller

Up to 64

(The total number of HDD VDs plus CacheCade VDs must not exceed 64)

Max. CacheCade Capacity per Controller
512GB







Warranty Details
Warranty Period : 5 Years
