Part Number: 424DAU-USB-C-CHARGER
Category
USB
 USB Charger
  STARTECH
Buy Price GST Ex Buy Price GST Inc
$329.09 $362.00
Stock GST Rate
Call 10%
Description
StarTech 4-Port Multi-Device USB-C Charger,

- 240W Total,
- Single Port 140W EPR,
- Screw Locking Ports, Ideal for Boardrooms
- USB-C desk charger with 4x USBC (single port 140W EPR Power Delivery 3.1);
- Charge up to four laptops simultaneously with a total power of 240W
- Runs cool under extended full-load use
- Compatible with 16 inch MacBook M3/M4 Pro/Max
- Ideal for meeting rooms

Detailed Description

4-Port Multi-Device USB-C Charger, 240W Total, Single Port 140W EPR, PD 3.1, Screw Locking Ports, Surface Mounting, Ideal for Boardrooms

Power and charge up to 4 USB-C devices that support USB Power Delivery with this 240W quad USB-C GaN Laptop Charger

Product ID: 424DAU-USB-C-CHARGER
  • HIGH-CAPACITY MULTI-DEVICE CHARGER: 4-Port USB-C PD3.1 charger delivers up to 140W EPR per port (240W total power) to charge 4 laptops/devices simultaneously; Rapidly charges the powerful MacBook Pro 16 (M3 Max/ M4 Pro/Max) from 0 to 50% in just 30 minutes
  • STAYS COOL WITH MINIMAL THERMAL THROTTLING: GaN charger runs cool for hours even during extended full-load use, delivering consistent fast charging; Features dual transformer topology to efficiently distribute heat while maintaining a compact design
  • SECURE & OUT-OF-SIGHT: 4 screw-locking USBC ports prevent unwanted disconnections; Pre-installed surface-mount bracket (100x100 VESA) for discreet mounting under tables or inside enclosures; Compatible with Noble Wedge, K-Slot, and Nano locks
  • SAFE & EFFICIENT: UL listed (IEC 62368-1), USB-IF/FCC/CE compliant, and DOE Level VI energy-efficient, providing protection against over-voltage, overheating, and over-current; Active Power Factor Correction significantly improves efficiency
  • WORKSPACE CHARGER: Consolidate chargers and free up desk space in meeting rooms/boardrooms, shared/open workspaces or reception desks, eliminating the need for shared wall outlets or cluttered table setups; Use as laptop/tablet charging station for education

Specifications

Warranty Information
Warranty
2 Years

Connector(s)
Input Connector(s)
1 - IEC 60320 C6
Output Connectors
4 - USB Type-C (24 pin) USB Power Delivery Only

Environmental
Operating Temperature
0�C to 30�C (32�F to 86�F)
Storage Temperature
-20�C to 85�C (-4�F to 185�F)
Humidity
Operation: 20% ~ 90% RH
Storage: 5% ~ 95% RH

Hardware
Number of Power Outlets
1
Ports
4
Industry Standards
USB Power Delivery 3.1

Packaging Information
Package Height
2.3 in [5.8 cm]
Package Length
6.9 in [17.4 cm]
Shipping (Package) Weight
2.4 lb [1.1 kg]
Package Width
7.3 in [18.5 cm]

Performance
MTBF
50410 Hours

Physical Characteristics
Color
Black
Product Height
1.7 in [43.7 mm]
Product Length
4.4 in [112.2 mm]
Weight of Product
1.7 lb [0.8 kg]
Product Width
5.1 in [130.1 mm]
Material
Plastic

Power
Input Voltage
100 - 240 AC
Input Current
4.0A
Output Voltage
15V DC
5V DC
9V DC
12V DC
20V DC
28V DC
Output Current
3A (5V, 9V, 12V, 15) / 5A (20V, 28V)
Plug Type
IEC 60320 C5 Power
Power Consumption (In Watts)
240 W

What's in the Box
Included in Package
1 - 240W USB-C Charger
4 - M3x4mm (5/32") Phillips Countersunk Machine Screws (Installed)
4 - M4x12mm (1/2") Phillips Countersunk Wood Screws
4 - M4x20mm (3/4") Phillips Countersunk Wood Screws
1 - 6ft [1.8m] AS/NZS 3112 to IEC-C5 Power Cord
1 - Mounting Plate (Installed)
1 - Quick-Start Guide Insert
Warranty Details
Warranty Period : 2 Years
