Features :
- Sleek &
Intelligent Design, Crystal Clear Image Quality
- Low light ability obtaining excellent image quality, even at low lux
of 0.01 lux
- SDI & DVI-I (HDMI) output
- Far end camera control
(FECC) via SDI UVC ability based on Codec FECC (zoom.us)
- Desktop
app control software included to control video settings
- Visca
control
- Belt drive technology � twin motors for smooth, quiet and
fast movement
- Larger FOV at 72.5 degrees with no video distortion
- 2D and 3D NR for best video quality in different lighting conditions
- Fully operational remote control with a power off function, resetting
the camera back to the start position
- Reverse mountable, standard
tripod screw on bottom of unit
Specifications :Video Format: SDI and DVI
1080p59.94/50/29.97/25; 720p59.94/50/29.97/25;
DVI--1080i 59.94/50.
Video Output: SDI &
DVI
Sensor: 1/2.3 inch 4K UHD CMOS sensor
Lens: f3.9
46.1mm(12Xzoom), E1.8-2.8
Angle of View: 72.5�
Rotation Angle: Pan
Rotation: � 170�
Tilt rotation:-30�+90�
Supports inverted
installation
Rotation Speed: Pan
Speed:0.1�-150� /s; Tile speed:
0.1�-80� /s
Preset: 10 via IR remote setting, (255 viaRS232) , preset
accuracy :0.2�
Auto/Manual
WhiteBalance,
Auto/Manual
Exposure (Iris,Shutter)
Control signal port: SB UVC FECC and 8 pin
mini DIN--RS232--VISCA/Pelco-D/Pelco-P protocol
Power voltage:
DC12V/2.0A; power port: HEC3800.
Max consumption:24W
Working
temperature:-5-45�C
Storage temperature:-20-60�C
Net weight: 1.5KG
Dimension: 220x190x173 mm
|
