Industry Standard |
EIA-RS310D
|
|
M/B Form Factor |
ATX(12" x 9.6"), CEB(12" x 10.5"), EEB(12" x 13")
|
|
Drive Bay |
� External 2.5"/3.5" hot-swap trays x 12 (pre-installed x
8), 5.25" x 1
� Internal 2.5" x 2 or 3.5" x 1
|
|
Power Supply |
Supports:
� Form factor: 80 Plus Platinum CRPS with PDB
cable management
� Watt: 800W/1200W/1600W/2000W |
|
Indicator |
Power status, HDD LED, LAN1/LAN2/LAN3/LAN4 LED, ID LED,
system fail activity LED
|
|
Front Control Panel |
Power switch, ID switch, system reset, NMI, USB 3.0 x 2
|
|
Chassis Security |
Supports padlock loop and Kensington lock slot |
|
Backplane |
Mini-SAS HD (SFF-8643), 12Gbps supported x 3 (pre-installed
x 2)
|
|
Cooling Fan |
� Middle: 92 x 25mm PWM fan x 3
� Rear: 120 x 25mm PWM
fan x 1
|
|
Expansion Slot |
Full-height PCIe slot x 9
|
|
Material |
� Material: SGCC
� Thickness: 1.0mm
|
|
Rail Kit |
Supports 28" tool-less & ball-bearing slide rail
|
|
Product Dimensions (DxWxH; Chassis Only) |
589.7 x 200 x 430mm
(23.22" x 7.87" x 16.93") |
|
Package Dimensions (DxWxH) |
860 x 610 x 360mm
|
|
Weight (Chassis Only) |
� Net weight: 16.95kg
� Gross weight: 21.28kg
|
|
Cubic Feet |
6.67
|
|
Container Information |
Single packing with pallets:
� 20': 100pcs
� 40':
220pcs
� 40' HQ: 264pcs |
